Danger due to suspended load! If the crane operator does not have an unobstructed view of the load, persons could be hit by the load and be killed or injured. Only operate the crane when the load, crane and operating range can be seen in full, or when working together with a banksman. |
|
|
Danger due to suspended load! If the crane operator stumbles or falls, the transmitter may be unintentionally activated. As a result of this, persons could be killed or injured. Only operate the crane from a safe position with secure footing. |
|
|
Danger due to careless handling of the transmitter! If the transmitter is handled carelessly (e.g. thrown, used to strike things, etc.) it will be damaged, no longer function properly and can send unintended signals to the crane. As a result of this, persons could be killed or injured. Lay the transmitter aside with care and do not use it as a substitute for a tool. |
|
Direction indicator |
LIFT and LOWER buttons |
|
| |
|
CRANE TRAVEL FORWARD and CRANE TRAVEL BACK buttons |
TROLLEY TRAVEL TOWARD LEFT and TROLLEY TRAVEL TOWARD RIGHT buttons |
To control the crane, press the following buttons either fully down
or halfway down: LIFT, LOWER, TROLLEY TRAVEL TOWARD LEFT, TROLLEY TRAVEL TOWARD
RIGHT, CRANE TRAVEL FORWARD and CRANE TRAVEL BACK.
● The direction of the crane, trolley and load hook appears on the display.
Operating a crane with two trolleys: See Operating a crane with two trolleys.
For a crane with one trolley, you can also switch between the displays for “I” or “II” on the transmitter, but only trolley I will be controlled.
Operating two cranes in tandem operation: See Operating cranes in tandem operation.
