Checking the bearing disc in the crane girder suspension



On all crane girder suspensions:

Circlip

Tensioning nut

Clamping joint

Groove in tensioning nut

*    Check above the clamping joint: The lower groove in the tensioning nut (underneath the circlip) must not be able to be seen.

*    If the groove can be seen, replace the bearing disc in the clamping joint. See Replacing the bearing disc in the clamping joint.
