Danger to persons from falling components!
The crane can fall and kill or injure people if it is not correctly attached and lifted. Attachment and loading should only be carried out by trained persons.
|
|
Danger to persons from falling components! The crane can fall and kill or injure people if it is not correctly attached and lifted. Attachment and loading should only be carried out by trained persons. |
Observe the following points amongst others:
|
Lifting tackle |
|
|
| |
|
|
Edge protection |
Place
suitable lifting tackle around the main girders.
Cover all edges of the main
girder with suitable edge protection.
If the profile rails (in which the energy chain is) protrude to the
side, lay wooden beams (wider than the profile rails) over the profile rails so
that they are not damaged on lifting.
Adjust the lifting tackle in
such a way that the main girder hangs straight when it is lifted.
Set down the main girders on
stands which have sufficient load capacity.
With the trolley installed underneath the main girder: The stands must be at least high enough that the rope is not buckled or pinched. Ideally, the stands should be high enough that the trolley load hook hangs freely.
|
|
|
Suspension eyelets |
Use suitable lifting tackle with
load hooks.
Connect at least three load
hooks in the suspension eyelets to the trolley.
Observe the occupational health
and safety requirements and lift the trolley.
Set down the trolley on stands
which have sufficient load-bearing capacity.
The stands must be so high that the load hooks of the trolley hang freely.
