Now the clamping buffers are mounted on the jib tip and on the jib arm start point.

    Rotate the clamping buffer so that the rubber buffers are pointing towards the trolley.

    Push the clamping buffer onto the lower flange on the jib arm.

    Tighten the vertical fillister-head screw slightly on one side.

    Then tighten the other vertical fillister-head screw and the horizontal fillister-head screw slightly.

    Align the clamping buffer so that both clamping claws are lying flush and parallel on the flange.

For the clamping buffer on the jib tip: also make sure that there is an interval of at least 5 mm between the end of the clamping buffer and the jib tip.

    Tighten the vertical fillister-head screws M16 (2x). 120 Nm.

    Then tighten the horizontal M12 fillister-head screw. 80 Nm.

    Push the rubber buffer right down onto the flange.
