All bolts and SL safety clips must be present.
For all bolts and SL safety clips:
All bolts and SL safety clips must be present.
All SL safety clips must be properly inserted and secured.
|
| |
|
Nominal diameter |
Abraded area at thinnest point |
Example of damage on the bolt.
Measure the diameter at multiple points. The bolt may be abraded by a
maximum of 2 mm at the thinnest point.
|
Drilled hole in steel part |
|
|
| |
|
Abraded area |
|
Example of damage on the fixed part.
Measure holes in the fixed parts at multiple points. The holes may be
maximally abraded by 2 mm.
If bolts or SL safety clips are missing, damaged, or more heavily
worn than permitted: replace bolt and SL safety clip.
