Danger from tilting and falling down! The crane girder is heavy and can kill or injure people if it tilts, becomes unbalanced, slips or similar during installation. Secure crane girders sufficiently during lifting and installation. Observe occupational health and safety requirements. |
Observe occupational
health and safety requirements and lift the crane girder under the I-beam.
Note
Use a suitable fork lift truck for lifting. Use suitable load lifting attachments and secure the crane girder!
On all crane girder suspensions:
|
Bolt |
Clamping joint |
|
| |
|
Crane girder |
Profile connection |
Lift the crane girder
under the I-beam in such a way that the profile connection is aligned exactly to
the clamping joint.
Insert bolt through
profile connection and clamping joint.
Secure bolt with SL safety
clip.
