Chain hoist
|
|
|
Chain hoist |
The chain hoist is next mounted on the hoist trolley.
|
|
The figures show the assembly of a chain hoist on the HB11 trolley. The assembly on an HB5, HB6, HB10 or HB22 trolley does not essentially differ. |
|
SL safety clip |
Cross bar HB10/HB11 |
|
| |
|
Chain hoist |
|
Bring the suspension
bracket of the chain hoist between the trolley or the cross bar HB10/HB11.
Fasten the chain hoist
with bolt and SL safety clip.
Install and connect the
chain hoist.
See the product manual for the chain hoist.
