Inspecting end caps



On all end caps on the crane track and on the crane girder:

Hexagon head screw M12x110

End cap



Cable slider

*    Inspect end caps. They should not be broken or otherwise damaged.

*    With festoon cable system: check cable slider on profile end. It must rest firmly in the end cap and should not slide.

*    Check the M12x110 hexagon head screw in the end cap. It must be present and free of any heavy deformation.

*    If the end cap, cable slider or hexagon head screw are damaged: replace the respective part.
