Inspecting bolts and SL safety clips



For all bolts and SL safety clips:

*    All bolts and SL safety clips must be present.

*    All SL safety clips must be properly inserted and secured.





Nominal diameter

Abraded area at thinnest point

Example of damage on the bolt.

*    Measure the diameter at multiple points. The bolt may be abraded by a maximum of 2 mm at the thinnest point.





Drilled hole in steel part



Abraded area



Example of damage on the fixed part.

*    Measure holes in the fixed parts at multiple points. The holes may be maximally abraded by 2 mm.





*    If bolts or SL safety clips are missing, damaged, or more heavily worn than permitted: replace bolt and SL safety clip.
