Overriding travel limit switch of a bypass control

Only with override travel limit switch



Using the “Limit switch” function, the travel limit switch of a bypass control (e.g. for tall machines which the crane is usually not allowed to travel over) can be overridden. The crane can then be moved into the blocked area at a slow speed (e.g. to set up the machine).

This function can only be opened using a direct access button.



Only with protected function “Override travel limit switch”

The function “Override travel limit switch” is protected by a PIN.



To unlock a protected function:

   When switching on or logging in the transmitter, enter the correct PIN for PIN level 1 or PIN level 3. See Entering the PIN.

●   The protected function is unlocked.

●   The direct access button has a black background. The protected function “Override travel limit switch” can now be used.





To lock a protected function:

   Log out or switch off the transmitter. When switching on or logging in, the correct PIN for PIN level 1 or PIN level 3 must be entered again. See Entering the PIN.

●   The protected function is locked.

●   The direct access button has a white background. The protected function “Override travel limit switch” is now unavailable.



Override travel limit switch
